2004 THERMAL ARC ARCMASTER 400 MST WELDER 400A OUTPUT, 208-460V

THE THERMAL ARC ARCMASTER 400 MST IS A MULTI-PROCESS INVERTER POWER SUPPLY DESIGNED FOR STICK, LIFT TIG, MIG, FLUX CORED, AND AIR CARBON ARC CUTTING AND GOUGING APPLICATIONS. THE UNIT OPERATES ON 208-230/460 VAC, SINGLE OR THREE-PHASE POWER AT 50/60 HZ, PROVIDING AN OUTPUT RANGE OF 5 TO 400 A AND A WELDING VOLTAGE RANGE OF 10 TO 36 V. IT FEATURES DIGITAL CONTROLS WITH VOLTAGE AND AMPERAGE DISPLAY, ADJUSTABLE INDUCTANCE, AND THERMAL OVERLOAD PROTECTION. THE SYSTEM IS BUILT TO IP23S STANDARDS AND COMPLIES WITH IEC 60974-1 AND CSA SPECIFICATIONS.
