2015 Brother Speedio R450X1 Vertical Machining Center, 10.10 HP, 16000 RPM, CNC Control

The 2015 Brother Speedio R450X1 is a high-precision CNC machining center designed to optimize production efficiency. It features a working area measuring 23.6 inches by 11.8 inches and supports a maximum table loading capacity of 265 lbs. Powered by a high-speed BT-30 spindle taper, the machine achieves spindle speeds up to 16,000 RPM along with a dedicated tapping speed of 6,000 RPM. Axis movement includes travels of 17.7 inches along the X-axis, 12.6 inches along the Y-axis, and 12.0 inches along the Z-axis. The system delivers rapid traverse rates of 1,969 IPM across all three axes, with controllable cutting feed rates ranging from 0.04 to 1,181 IPM. Equipped with a 14-tool capacity automatic tool changer, the unit accommodates tools up to 7.9 inches in length, 3.1 inches in diameter, and 6.6 lbs in weight. Tool change cycles are exceptionally fast, executing tool-to-tool transitions in 0.7 seconds and chip-to-chip transitions in 1.5 seconds. Operational control is managed via the integrated Brother CNC C-00 control system. For optimal thermal management and chip evacuation, the machine includes coolant through the spindle, a dedicated coolant tank, and two coolant pumps. Machine hour metrics show an operation time of 5,690 hours, a total operation time of 15,690 hours, and a power-on time of 56,595 hours. Overall, these technical specifications highlight a robust platform capable of precise, rapid, and continuous manufacturing operations.
