2016 Southwestern Industries Trak DPM2 3 Axis CNC Bed Mill W/PDB - 49x9 Table, 5000 RPM, 3 HP

The TRAK DPM SX2P is a 3-axis CNC bed mill equipped with the ProtoTRAK SMX CNC control system. It features a 49" x 9" table supporting up to 1,320 lbs load capacity, with three 0.63" T-slots on a 2.5" pitch and a table height of 37" from the bed. Axis travels measure 31" (32" maximum) on the X-axis, 16" on the Y-axis, and 27" on the Z-axis, complemented by a 5" quill travel and a rapid traverse rate of 150 IPM across all axes. Powered by a 3 HP motor, its R-8 taper spindle with a 3 3/8" quill diameter operates within a programmable electronic variable speed range of 40 to 5,000 RPM across low and high ranges. The distance from the spindle center to the column face is 18". Electrical requirements include 110V, 1-phase, 10A for the control system and 220V, 3-phase, 11A at 60 Hz for the machine itself. Overall physical specifications comprise approximate dimensions of 72" x 64" x 98" and a total machine weight of 4,000 lbs.
