2017 DOOSAN D30S-7 PNEUMATIC TIRE FORKLIFT, 6,000 LB CAPACITY, DIESEL, 61 HP, 2.4L ENGINE

THE 2017 DOOSAN D30S-7 IS A DIESEL-POWERED, SIT-DOWN PNEUMATIC TIRE FORKLIFT DESIGNED FOR HEAVY-DUTY INDUSTRIAL APPLICATIONS. PART OF THE PRO-7 SERIES, IT FEATURES A 2.4L DOOSAN D24NAP FOUR-CYLINDER ENGINE THAT DELIVERS APPROXIMATELY 61 HORSEPOWER (46 KW) AND 193 FT-LB OF TORQUE AT 1,600 RPM, MEETING EPA TIER 4 EMISSION STANDARDS USING ULTRA LOW PM COMBUSTION TECHNOLOGY. THE MACHINE OFFERS A NOMINAL LOAD CAPACITY OF 6,000 LBS (3,000 KG) AT A 24-INCH (500 MM) LOAD CENTER. TECHNICAL DIMENSIONS INCLUDE AN OVERALL WIDTH OF 47.1 INCHES (1,197 MM), A WHEELBASE OF 66.9 INCHES (1,700 MM), AND A TURNING RADIUS OF 93.1 INCHES (2,365 MM). PERFORMANCE SPECIFICATIONS HIGHLIGHT A TRAVEL SPEED OF UP TO 12.4 MPH LOADED AND A HOISTING SPEED OF APPROXIMATELY 100 FPM (0.51 M/S). THE HYDRAULIC SYSTEM INCLUDES A LIFT AND TILT LOCKING VALVE AS PART OF THE OPERATOR SENSING SYSTEM (OSS), WHICH ALSO FEATURES A MAST INTERLOCK AND A NEUTRAL SHIFT FUNCTION FOR ENHANCED SAFETY. STANDARD EQUIPMENT INCLUDES VIRTUALLY MAINTENANCE-FREE OIL-COOLED DISC BRAKES, A POWER REVERSAL TRANSMISSION, AND AN ERGONOMIC OPERATOR COMPARTMENT WITH A CENTRALIZED INSTRUMENT PANEL AND ADJUSTABLE SEATING. GROUND CLEARANCE IS RATED AT 4.1 INCHES (105 MM) BELOW THE MAST WHEN LOADED, PROVIDING STABILITY ACROSS VARIOUS SURFACES.
