2021 SCHENCK PROCESS HYGIENIC BAG DUMP

• INTEGRAL 19HSER2 FILTER WITH (2) POLYESTER CARTRIDGES • 304 STAINLESS STEEL CONSTRUCTION (ALL PRODUCT CONTACT AREAS) • CONTINUOUS WELDS: EXTERIOR CLEANED FREE OF SLAG; INTERIOR FINISHED TO RA32 MAX • REMOVABLE ROD-STYLE GRATE; HINGED DOOR WITH GAS SPRINGS; BAG DUMP ACCESS SWITCH (NEMA 4X) • NOMINAL 55° HOPPER ANGLE WITH INTEGRAL SQUARE-TO-ROUND TRANSITION • HOPPER DISCHARGE: 10″ 150# FLANGE PATTERN • (2) HYGIENIC-DESIGN DIAPHRAGM VALVES • TIMER & (2) SOLENOID VALVES IN NEMA 4X ENCLOSURE, 24 VDC • 2″ TRI-CLOVER FERRULE FOR CLEAN-IN-PLACE • 6″ O.D. TRI-CLOVER FERRULE EXHAUST PORT • AIR REQUIREMENT: 80–100 PSIG CLEAN, DRY AIR • MAGNEHELIC GAUGE • (4) LEG SUPPORTS
