2023 FANUC M-900IB/280L ARTICULATED ROBOT, 280KG PAYLOAD, 3103MM REACH, R-30IB PLUS CONTROLLER

THE 2023 FANUC M-900IB/280L IS A SIX-AXIS ARTICULATED ROBOT DESIGNED FOR HIGH-PAYLOAD APPLICATIONS, FEATURING A 280 KG CAPACITY AND A 3103 MM HORIZONTAL REACH. THIS LONG-ARM VARIANT IS ENGINEERED FOR TASKS SUCH AS SPOT WELDING, DISPENSING, MACHINE LOADING, MACHINE TENDING, PART TRANSFER, ASSEMBLY, COATING, AND MATERIAL REMOVAL. THE ROBOT EXHIBITS A REPEATABILITY OF ±0.3 MM AND HAS A MASS OF 1600 KG. IT SUPPORTS FLOOR AND INVERTED MOUNTING CONFIGURATIONS. AXIS MOTION SPEEDS ARE 110°/S FOR J1, 105°/S FOR J2, 100°/S FOR J3, 125°/S FOR J4 AND J5, AND 205°/S FOR J6. THE MOTION RANGE FOR THE AXES IS J1 ±370°, J2 ±151°, J3 ±224°, J4 ±720°, J5 ±250°, AND J6 ±720°. THE SYSTEM IS EQUIPPED WITH A FANUC R-30IB PLUS CONTROLLER, WHICH CAN BE CONFIGURED IN EITHER AN A OR B CABINET. THE DESIGN FOCUSES ON HEAVY-DUTY PERFORMANCE AND AN EXTENDED REACH FOR VERSATILE INDUSTRIAL AUTOMATION.
