Allen Bradley MPL-A4530K-MJ72AA Servo Motor, 2.5 kW Power, 10.9 NM Torque, 3000 RPM Speed

The Allen Bradley MPL-A4530K-MJ72AA is an MP-series low-inertia brushless AC servo motor designed for high-performance automation applications requiring rapid acceleration and deceleration. This 3-phase motor operates at 230 VAC and delivers a continuous power output of 3.4 HP (2.5 kW). Key specifications include a rated torque of 10.9 NM, a peak torque of 32.7 NM, a rated speed of 3000 RPM, and a maximum speed of 5000 RPM. Electrical characteristics feature a rated current of 10.0 A and a peak current of 30.0 A. It incorporates a 262,144 count absolute multi-turn encoder for precise position feedback. The motor features a 4-inch (100mm) frame, a keyed shaft, and is configured without an integral brake. Connectivity is managed via SpeedTec DIN connectors, providing an IP65/67 ingress protection rating.
