BALDOR ECP84402T-4 AC MOTOR, 100 HP, 460 V, 3-PHASE, 3565 RPM, 405TS FRAME, TEFC

THE BALDOR ECP84402T-4 IS A 100 HP, 3-PHASE AC MOTOR ENGINEERED FOR 460 V, 60 HZ ELECTRICAL SYSTEMS. IT OPERATES WITH A SYNCHRONOUS SPEED OF 3600 RPM AND A FULL-LOAD SPEED OF 3565 RPM, DRAWING 110 A AT FULL LOAD. THIS MOTOR FEATURES A ROBUST 405TS CAST IRON FRAME AND A TEFC (TOTALLY ENCLOSED FAN COOLED) ENCLOSURE, DESIGNED FOR FOOT MOUNTING. KEY TECHNICAL SPECIFICATIONS INCLUDE A NEMA PREMIUM EFFICIENCY OF 95.8% AND A 1.25 SERVICE FACTOR. IT COMPLIES WITH NEMA DESIGN B, INCORPORATES CLASS F INSULATION, AND IS RATED FOR CONTINUOUS DUTY IN AMBIENT TEMPERATURES UP TO 40°C.
