BALLUFF BIS0099 CONTROLS PLCS, 19.2-28.8 VDC VOLTAGE, 350 MA CURRENT, 70, 455 KHZ FREQUENCY

THE BALLUFF BIS0099, ALSO IDENTIFIED AS BIS C-6002-019-XXX-03-KL2, IS AN LF PROCESSOR UNIT DESIGNED FOR DIN RAIL MOUNTING, HOUSED IN ALUMINUM, AND PROTECTED TO IP20. IT OPERATES WITHIN A VOLTAGE RANGE OF 19.2 TO 28.8 VDC, WITH A MAXIMUM CURRENT CONSUMPTION OF 350 MA. THE UNIT SUPPORTS OPERATING FREQUENCIES OF 70 KHZ AND 455 KHZ. IT FEATURES A 19-PIN TERMINAL STRIP FOR CONNECTIONS AND ALLOWS FOR THE INTEGRATION OF TWO CONNECTABLE READ/WRITE HEADS OR ANTENNAS. COMMUNICATION IS FACILITATED VIA A PROFIBUS DP SLAVE INTERFACE. PHYSICAL DIMENSIONS MEASURE 165 MM IN HEIGHT, 46 MM IN WIDTH, AND 115 MM IN DEPTH. ITS OPERATIONAL TEMPERATURE RANGE EXTENDS FROM 0 TO +60 DEGREES CELSIUS.
