Belden PG07998-11 OS2 Fiber, 48-Fiber, 9.8 mm OD, -30/+70°C Op Temp, 500 N Max Tensile

THE BELDEN PG07998-11 IS A 48-FIBER SINGLE-MODE OS2 OPTICAL FIBER CABLE DESIGNED FOR INDOOR/OUTDOOR APPLICATIONS. IT FEATURES A CENTRAL LOOSE TUBE CONSTRUCTION WITH 9/125ΜM FIBERS, GEL-FILLED FOR MOISTURE PROTECTION, AND USES E-GLASS YARN AS A STRENGTH MEMBER. THE CABLE EXHIBITS A MAXIMUM ATTENUATION OF 0.35 DB/KM AT 1310 NM AND 0.22 DB/KM AT 1550 NM. ITS OUTER JACKET IS UV-RESISTANT, FLAME-RETARDANT, AND COMPOSED OF LOW SMOKE ZERO HALOGEN (LSZH) MATERIAL, COMPLIANT WITH IEC 60332-3-24 AND IEC 61034-2. THE NOMINAL OUTER DIAMETER IS 9.8 MM. OPERATIONAL TEMPERATURE RANGES FROM -30°C TO +70°C, WITH AN INSTALLATION TEMPERATURE RANGE OF -10°C TO +50°C. KEY MECHANICAL SPECIFICATIONS INCLUDE A MAXIMUM OPERATIONAL TENSILE LOAD OF 500 N, CRUSH RESISTANCE OF 1500 N/10CM, AND AN OPERATIONAL BEND RADIUS OF 10 TIMES THE OUTER DIAMETER.
