B&R 8BVI0055HWS0.000-1, SINGLE-AXIS INVERTER DRIVE, 5.5KW POWER, 7.6A OUTPUT, 0-480VAC
Aucto ID: #111804
Ends in:
230efc4c-16f5-45a1-a8b8-882d77c9416b
Location: El Paso, Texas, United States
Logistics:
Rigging:
Included
Loading:
Included
Shipping:
Buyer
buy now
Buy Now: Submit an offer or purchase immediately!
FAQsVerified Seller - Since 2026
3106Product Description
THE B&R 8BVI0055HWS0.000-1 IS AN ACOPOS MULTI SINGLE-AXIS INVERTER DRIVE MODULE DESIGNED FOR WALL-MOUNTABLE INSTALLATION. THE MODULE OPERATES WITH A 25 VDC SUPPLY, TOLERATING +/-1.6% DEVIATION. OUTPUT SPECIFICATIONS INCLUDE 7.6 AMPS, THREE-PHASE, WITH A VOLTAGE RANGE OF 0-480 VAC AND A FREQUENCY RANGE OF 0-500 HZ. ITS RATED OUTPUT POWER IS 5.5 KW. IT INTEGRATES TWO TRIGGER INPUTS AND TWO ENABLE INPUTS FOR CONTROL. THE OPERATING TEMPERATURE RANGE IS SPECIFIED FROM 5 TO 55 DEGREES CELSIUS. THE UNIT HAS AN IP20 ENCLOSURE RATING.
Core Specifications
Manufacturer: B&R
Model: 8BVI0055HWS0.000-1
Condition: Fair
- Item functions as originally intended, shows signs of normal wear.Category:
INDUSTRIAL PARTS > ELECTRICAL COMPONENTS > POWER INVERTERSLogistics
