COMMSCOPE O-001-DF-8GI-F01NS/EZ CABLE, 1 FIBER, G.657.A1, 4.8X2.5 MM DIMENSIONS

THE COMMSCOPE O-001-DF-8GI-F01NS/EZ IS A SINGLE-FIBER OUTDOOR FLAT DROP CABLE DESIGNED WITH BEND-INSENSITIVE SINGLE-MODE FIBER, COMPLIANT WITH G.657.A1 AND G.652.D STANDARDS. IT FEATURES A UV-RESISTANT BLACK POLYETHYLENE (PE) OUTER JACKET AND INCORPORATES DIELECTRIC STRENGTH MEMBERS. NOMINAL CABLE DIMENSIONS ARE 4.8 MM BY 2.5 MM. OPERATIONAL SPECIFICATIONS INCLUDE AN ATTENUATION OF 0.35 DB/KM AT 1310 NM, 0.25 DB/KM AT 1550 NM, AND 0.25 DB/KM AT 1625 NM. THE CABLE MAINTAINS A MINIMUM INSTALLED BEND RADIUS OF 10 MM AND AN OPERATIONAL BEND RADIUS OF 20 MM. IT IS DESIGNED FOR AN OPERATING TEMPERATURE RANGE OF -40°C TO +70°C AND A STORAGE TEMPERATURE RANGE OF -40°C TO +75°C. CRUSH RESISTANCE IS RATED AT 200 N/10 CM, WITH SHORT-TERM TENSILE STRENGTH AT 200 N AND LONG-TERM TENSILE STRENGTH AT 70 N. THIS CABLE ADHERES TO IEC 60794-1-2 STANDARDS.
