DVT 530MR, SENSORS, 640X480 PIXELS RESOLUTION, 60 FPS ACQUISITION RATE, 24 VDC POWER

THE DVT 530MR SMARTIMAGE SENSOR IS A SELF-CONTAINED MACHINE VISION SYSTEM. IT FEATURES A CCD IMAGER PROVIDING A RESOLUTION OF 640 X 480 PIXELS AND AN ACQUISITION RATE OF UP TO 60 FRAMES PER SECOND. THE UNIT INCORPORATES AN ON-BOARD DIGITAL SIGNAL PROCESSOR (DSP) FOR IMAGE PROCESSING. CONNECTIVITY IS PROVIDED VIA 10/100 BASE T ETHERNET FOR DATA TRANSFER AND CONTROL, ALONGSIDE AN RS-232 SERIAL PORT FOR CONFIGURATION. IT INCLUDES INTEGRATED DIGITAL I/O FOR TRIGGER AND CONTROL SIGNALS, AND SUPPORTS BOTH INTERNAL AND EXTERNAL LIGHTING OPTIONS. THE SYSTEM OPERATES ON A 24 VDC POWER SUPPLY.
