FANUC, A05B-2691-B002 R-30IB, ROBOT CONTROLLER, 19KG, 200-230V, 480X420X190MM, IP20

THE FANUC A05B-2691-B002 R-30IB COMPACT PLUS IS A ROBOT CONTROLLER ENGINEERED FOR COMPACT AUTOMATION SYSTEMS, SPECIFICALLY DESIGNED FOR THE FANUC SCARA SERIES AND OTHER SMALL ROBOT MODELS. AS A COMPONENT OF THE R-30IB PLUS GENERATION, IT FEATURES AN ULTRA-COMPACT FORM FACTOR WITH APPROXIMATE DIMENSIONS OF 480MM (H) X 420MM (W) X 190MM (D) AND A WEIGHT OF APPROXIMATELY 19 KG. THE CONTROLLER OPERATES ON A 3-PHASE AC INPUT, 200-230V AT 50/60 HZ. IT INTEGRATES FANUC'S DUAL CHECK SAFETY (DCS) SYSTEM FOR SAFE MOTION AND SAFE ZONE FUNCTIONALITY. USER INTERACTION IS FACILITATED VIA THE IPENDANT TOUCH AND WEB-BASED IRPROGRAMMER INTERFACES, ENABLING BOTH PENDANT AND BROWSER-BASED PROGRAMMING. STANDARD CONNECTIVITY INCLUDES ETHERNET PORTS, WITH OPTIONAL SUPPORT FOR VARIOUS INDUSTRIAL NETWORK PROTOCOLS SUCH AS ETHERNET/IP, PROFINET, AND DEVICENET. THE UNIT IS SPECIFIED FOR AN OPERATING TEMPERATURE RANGE OF 0 TO 45°C AND MAINTAINS AN IP20 PROTECTION RATING.
