Fiplex ATBFCR023 RDL-2N1A4 Lab Instruments, DC-4.0 Ghz Freq, 200W Cw Power

The Fiplex ATBFCR023 RDL-2N1A4 is an electromagnetic device categorized as a lab instrument, primarily designed for high-power radio frequency signal switching and routing applications. This unit integrates twelve Relcomm RDL-2N1A4 high power SPDT RF relays. Each RDL-2N1A4 relay is an electromechanical single-pole double-throw switch engineered for operation across a frequency range spanning DC to 4.0 GHz. These relays are characterized by a 50-ohm impedance and possess high power handling capabilities, with specifications such as 200W continuous wave at 100 MHz, 100W continuous wave at 1 GHz, and 50W continuous wave at 3 GHz. Typical performance metrics for these relays include an isolation of 60 dB at 1 GHz and an insertion loss of 0.2 dB at 1 GHz. The device leverages these twelve integrated relays to facilitate complex RF signal management.
