KUKA Servo Drive Art No. 00198263 KPP 600-20-2X40 Type: EMCBP2D3444BE531

The KUKA KPP 600-20 2x40 (Article No. 00-198-263 / 2000198263) is an industrial KUKA Power Pack designed as a drive power supply unit for KRC4 robot control cabinets. Operating as a core control cabinet component, the KPP generates the intermediate circuit DC voltage used to supply energy to internal drive controllers and external robotic drives. It operates on an input specification of 3/PE AC 400/480V at 20A and 50/60Hz, delivering a rated output capacity of 14/17 kW. In addition to powering the intermediate circuit, this specific configuration features integrated axis amplifiers configured for two 40A drive channels (2x40), enabling direct regulation and control of attached servo drives. The unit weighs approximately 8 kg and carries UL certification for industrial automation standards. Manufactured in Germany, the module provides stable and efficient energy management necessary for high-performance operation in demanding industrial robotic systems, maintaining precise control over connected motor axes within the KRC4 architecture.
