Leoni 1719191-1 Coaxial Cable 0.14 Sqmm RG174 DAC300 50-Ohm

THE LEONI DAC300 1719191-1 IS A FLEXIBLE, SINGLE-SHIELDED RG174 COAXIAL CABLE DESIGNED FOR HIGH-FREQUENCY SIGNAL TRANSMISSION AND TELECOMMUNICATIONS APPLICATIONS. IT FEATURES A CROSS-SECTIONAL AREA OF 0.14 SQUARE MILLIMETERS AND UTILIZES A STRANDED CENTER CONDUCTOR CONFIGURATION, WHICH PROVIDES ENHANCED FLEXIBILITY FOR EASE OF DEPLOYMENT IN COMPACT INDUSTRIAL SPACES. THE CABLE CORE IS INSULATED WITH A POLYETHYLENE DIELECTRIC MATERIAL, MEASURING NOMINALLY 0.060 INCHES IN DIAMETER, AND IS SURROUNDED BY AN 88% COVERAGE PROTECTIVE BRAID SHIELD TO DELIVER EXCELLENT SHIELDING EFFECTIVENESS AGAINST ELECTROMAGNETIC INTERFERENCE. ENCASED IN A DURABLE POLYVINYL CHLORIDE JACKET WITH AN OVERALL NOMINAL OUTSIDE DIAMETER OF 0.101 INCHES, THIS 50-OHM CHARACTERISTIC IMPEDANCE CABLE EXHIBITS A VELOCITY FACTOR OF APPROXIMATELY 66% AND A NOMINAL CAPACITANCE OF 31 PICOFARADS PER FOOT. THIS PARTICULAR LOT CONFIGURATION CONSISTS OF A BULK TOTAL QUANTITY OF 30,000 FEET OF HIGH-QUALITY RF COAXIAL WIRE.
