Lot of 120 MOLEX F04FA03144 1200710001 Attachable Micro Change

THE MOLEX 1200710001 IS A MICRO-CHANGE (M12) INDUSTRIAL ELECTRICAL CONNECTOR. IT FEATURES A 4-POLE FEMALE CONFIGURATION WITH STRAIGHT ORIENTATION AND IDC (INSULATION DISPLACEMENT CONNECTOR) TERMINATION. DESIGNED FOR CABLE MOUNTING AND FREE-HANGING APPLICATIONS, IT ACCOMMODATES WIRE SIZES OF 22 AWG (0.34MM²) AND CABLE DIAMETERS RANGING FROM 3.3MM TO 6.6MM. THE CONNECTOR SUPPORTS A MAXIMUM CURRENT OF 4.0A PER CONTACT AND A MAXIMUM VOLTAGE OF 250V AC/DC. ITS CONTACTS ARE CONSTRUCTED FROM COPPER ALLOY WITH GOLD PLATING, WHILE THE RECEPTACLE IS MADE FROM PA (NYLON) AND THE NUT FROM BRASS. OPERATIONAL WITHIN A TEMPERATURE RANGE OF -25°C TO +85°C, IT POSSESSES AN IP67 RATING FOR INGRESS PROTECTION AND A UL 94V-0 FLAMMABILITY RATING.
