LOT OF 2400 0272240008 CG130B SEMICONDUCTOR SG10UKJ.1

THE LITTELFUSE SG10UKJ.1, IDENTIFIED BY MODEL 0272240008 CG130B, IS A 2-TERMINAL GAS DISCHARGE TUBE (GDT) DESIGNED FOR TRANSIENT OVERVOLTAGE PROTECTION. THIS DEVICE FEATURES A DC SPARKOVER VOLTAGE OF 130 VDC ±20% AND AN IMPULSE SPARKOVER VOLTAGE NOT EXCEEDING 500 V AT A 1 KV/ΜS RATE OF RISE. IT EXHIBITS A MINIMUM INSULATION RESISTANCE OF 1 GΩ AT 100 V AND A MAXIMUM CAPACITANCE OF 1.5 PF AT 1 MHZ. THE GDT IS RATED FOR A MAXIMUM IMPULSE DISCHARGE CURRENT OF 10 KA FOR A SINGLE 8/20 ΜS PULSE OR 5 KA FOR TEN 8/20 ΜS PULSES. ITS MAXIMUM AC DISCHARGE CURRENT CAPACITY IS 20 A FOR ONE SECOND AT 50/60 HZ. THE COMPONENT OPERATES EFFECTIVELY WITHIN A TEMPERATURE RANGE OF -40°C TO +90°C.
