McGraw-Edison Substation Transformer with Load Tap Changing

McGraw-Edison Substation Transformer with Load Tap Changing 45,000 KVA - OA 60,000 KVA - FA 75,000 KVA - FA HV: 140,000 Delta with standard no load straddle taps - BIL 650 Kv LV: 14,000 Y/8080 - BIL 110 Kv 3 Phase 60 Hertz Class OA/FA/FA Rise 65 C Configuration: Delta / Wye Impedance = 13.9% @ 45 MVA Standard Gauges & Valve Package Included 33 Step Secondary with Load Tap Changing LV: 14,000 Y Nominal with 16+ and 16- Voltage Steps Range is from: High(Step 32) 16,100 to Low(Step 1)11,900 Volts All COPPER Windings Fan Packaged and Fan Controls Included HV Bushing Well Current Transformers Included: Multi-Ratio Units Manufactured NEW 1983 High Voltage Taps 1. 147,000 volts 2. 143,500 volts 3. 140,000 volts 4. 136,500 volts 5. 133,000 volts Shipping Stripped Weight less Oil: 173,000 lbs. Total Assembled Weight including Oil: 285,000 lbs. PLEASE UNDERSTAND THAT EVERYTHING IS SOLD “AS IS, WHERE IS”…PLEASE READ THE AUCTION CONTRACT. WE ENCOURAGE MAKING AN INSPECTION. PLEASE CALL 310-487-3800 FOR INSPECTION. THANK YOU.
