REXROTH MSK030C-0900-NN-M1-UGO-NNNN R911308683 SERVO MOTOR, 0.8 NM TORQUE

THE REXROTH MSK030C-0900-NN-M1-UGO-NNNN IS A SYNCHRONOUS SERVO MOTOR WITH NATURAL CONVECTION COOLING, DESIGNED FOR A MAXIMUM AC OPERATING VOLTAGE OF 600 V. IT PROVIDES A CONTINUOUS STALL TORQUE OF 0.8 NM AND A CONTINUOUS STALL CURRENT OF 1.5 A. THE MOTOR DELIVERS A MAXIMUM ROTATIONAL SPEED OF 9000 MIN-1. ELECTRICAL CHARACTERISTICS INCLUDE A BACK EMF CONSTANT OF 35.6 V/1000 MIN-1 AND A TORQUE CONSTANT OF 0.58 NM/A. THIS MODEL IS CONFIGURED WITH AN M1 HIPERFACE SINGLE-TURN ABSOLUTE ENCODER FOR PRECISE POSITION AND SPEED FEEDBACK. IT FEATURES A PLAIN SHAFT WITHOUT A KEYWAY AND IS SUPPLIED WITHOUT AN INTEGRATED HOLDING BRAKE. THE MOTOR ADHERES TO AN IP65 PROTECTION CLASS.
