SYNRAD FHFL50-U FHFL020220009 FLYER MARKING HEAD LASERV SYSTEM

THE SYNRAD FHFL50-U, ALSO IDENTIFIED BY PART NUMBER FHFL020220009, IS A 2-AXIS, FULLY DIGITAL SCANNING HEAD DESIGNED FOR INDUSTRIAL CO2 LASER APPLICATIONS. THIS SYSTEM SUPPORTS PRECISE MARKING, ENGRAVING, AND CUTTING OPERATIONS. IT OPERATES WITH STANDARD CO2 LASER WAVELENGTHS, TYPICALLY 10.6 ΜM. THE SCANNING HEAD IS ENGINEERED TO HANDLE OPTICAL POWER LEVELS UP TO 250W AND FEATURES HIGH-SPEED DIGITAL GALVANOMETERS, ENABLING VECTOR SCAN SPEEDS UP TO 6000 MM/S. THE OPTICAL SYSTEM INCORPORATES F-THETA SCAN LENSES, PROVIDING A CONFIGURABLE WORKING AREA THAT COMMONLY RANGES FROM 70X70 MM TO 300X300 MM, DEPENDING ON THE SPECIFIC LENS CONFIGURATION. CONTROL IS MANAGED VIA A DIGITAL INTERFACE, INTEGRATING WITH COMPATIBLE LASER MARKING CONTROLLERS.
