YOKOGAWA SC402G-E-2-E/Q/PM/U ANALYZER, COND, RESIST, 4-20 MA, 100-240V POWER, PANEL MOUNT

THE YOKOGAWA SC402G-E-2-E/Q/PM/U IS AN EXA SERIES INDUSTRIAL ANALYZER DESIGNED FOR CONTINUOUS MEASUREMENT AND CONTROL OF CONDUCTIVITY, RESISTIVITY, SALINITY, AND CONCENTRATION. IT SUPPORTS A BROAD MEASUREMENT RANGE, TYPICALLY FROM 0.00 ΜS/CM TO 2000 MS/CM FOR CONDUCTIVITY AND UP TO 20 MΩ·CM FOR RESISTIVITY, DEPENDENT ON THE CONNECTED SENSOR. THE UNIT ACCEPTS VARIOUS CONDUCTIVITY AND RESISTIVITY SENSOR INPUTS AND PROVIDES A STANDARD 4-20 MA DC ANALOG OUTPUT SIGNAL WITH HART COMMUNICATION PROTOCOL FOR INTEGRATION INTO PROCESS CONTROL SYSTEMS. THIS MODEL OPERATES ON A 100-240 V AC, 50/60 HZ POWER SUPPLY, AS INDICATED BY THE -E SUFFIX, AND IS CONFIGURED FOR PANEL MOUNTING, DENOTED BY THE -PM SUFFIX. KEY FEATURES INCLUDE AUTOMATIC TEMPERATURE COMPENSATION CAPABILITIES AND AN INTEGRATED LCD FOR LOCAL DISPLAY OF MEASURED VALUES AND PARAMETERS.
