CONTROL MICROSYSTEMS TBUP4-102-01-0-1, CONTROLS PLCS, 11-30VDC IN, 2AI, 8DI, 8DO, RS-232/485

THE CONTROL MICROSYSTEMS TBUP4-102-01-0-1 IS A PROGRAMMABLE LOGIC CONTROLLER (PLC) DESIGNED FOR OPERATION WITH AN 11-30 VDC POWER INPUT, DRAWING A MAXIMUM OF 23.7W. THIS UNIT INCORPORATES AN AIO-102 ANALOG INPUT MODULE FEATURING TWO CHANNELS WITH 16-BIT RESOLUTION, SUPPORTING INPUT RANGES SUCH AS 0-20MA, 4-20MA, 0-5V, 0-10V, +/-5V, AND +/-10V. A DIO-101 DIGITAL I/O MODULE PROVIDES EIGHT CONFIGURABLE DIGITAL INPUTS FOR WET OR DRY CONTACTS, ALONGSIDE EIGHT RELAY DIGITAL OUTPUTS RATED FOR 3A AT 30VDC OR 250 VAC. COMMUNICATION IS FACILITATED BY A COM-100 MODULE, OFFERING ONE RS-232 PORT AND ONE RS-485 PORT. THE CONTROLLER IS SPECIFIED FOR AN OPERATING AMBIENT TEMPERATURE UP TO 70 DEGREES CELSIUS, ALIGNING WITH A T4 TEMPERATURE CODE.
