Corning 012K81-33130-A1, Riser Mm Fiber Cable, 12 Fibers, Om1 62.5 Μm, 12.3 Mm Od
Aucto ID: #110145
Ends in:
b54a013f-3ebe-43da-a1e1-6010b378707e
Location: El Paso, Texas, United States
Logistics:
Rigging:
Included
Loading:
Included
Shipping:
Buyer
buy now
Buy Now: Submit an offer or purchase immediately!
FAQsVerified Seller - Since 2026
3106Product Description
THE CORNING 012K81-33130-A1 IS A 12-FIBER, OM1 62.5 ΜM MULTIMODE MIC TIGHT-BUFFERED INTERLOCKING ARMORED RISER CABLE. IT FEATURES AN ORANGE FLAME-RETARDANT PVC OUTER JACKET WITH A NOMINAL OUTER DIAMETER OF 12.3 MM. THIS CABLE IS DESIGNED FOR RISER APPLICATIONS, MEETING UL 1666 STANDARDS FOR FLAME RESISTANCE. IT OPERATES WITHIN A TEMPERATURE RANGE OF -20°C TO 70°C. THE MINIMUM INSTALLATION BEND RADIUS IS 18.5 CM, WITH AN OPERATIONAL BEND RADIUS OF 12.3 CM. MAXIMUM INSTALLATION TENSILE STRENGTH IS RATED AT 2200 N, AND CRUSH RESISTANCE IS 2200 N/10CM. TYPICAL ATTENUATION FOR THE 62.5 ΜM MULTIMODE FIBER IS 3.5 DB/KM AT 850 NM AND 1.5 DB/KM AT 1300 NM.
Core Specifications
Manufacturer: CORNING
Model: 012K81-33130-A1
Condition: Fair
- Item functions as originally intended, shows signs of normal wear.Category:
INDUSTRIAL PARTS > ELECTRICAL COMPONENTS > ELECTRICAL WIRE > FIBER OPTIC CABLELogistics
Rigging Responsibility:
Included
Loading Responsibility:
Included
Shipping Responsibility:
Buyer
