BERKSHIRE LD-1340E MANUAL LATHES

Technical Description

The Berkshire LD-1340E Manual Lathe is a high-precision engine lathe designed for demanding metalworking applications. Featuring a robust swing capacity of 12.99 inches over the bed and a distance between centers of 39.37 inches, this lathe provides ample workspace for turning a wide range of workpieces. The machine is built with a hardened and ground bedway for superior accuracy and durability, ensuring long-term reliability in industrial environments. The spindle is equipped with a D1-4 camlock interface and a Morse #3 taper, supporting versatile tooling and workholding options. The lathe offers 8 spindle speeds, ranging from 70 to 2,000 RPM, allowing for precise control across various materials and operations. The leadscrew features an 8 T.P.I. pitch, and the machine supports both metric and imperial threading, with a metric thread range of 0.4 to 7 mm. Longitudinal feed rates are adjustable from 0.002" to 0.0548" per revolution, enabling fine surface finishes and accurate cuts. The lathe is powered by a 2 HP, 220V single-phase motor, making it suitable for standard shop power supplies. Standard accessories include a gap bed, complete electric control unit, change gears, 4-way tool post, center sleeve, rear splash guard, and a rapid foot brake for enhanced safety and convenience. The machine’s construction from high-tensile cast iron ensures stability and vibration resistance during operation. With its combination of precision, power, and versatility, the Berkshire LD-1340E Manual Lathe is an ideal choice for professional workshops and industrial manufacturing settings.
