2020 FANUC LR MATE 200ID/7L ARTICULATED ROBOT, 7KG PAYLOAD, 911MM REACH, R-30IB MATE PLUS

THE 2020 FANUC LR MATE 200ID/7L IS A HIGH-SPEED, SIX-AXIS ARTICULATED ROBOT DESIGNED FOR SMALL-PAYLOAD APPLICATIONS REQUIRING AN EXTENDED REACH. THIS MODEL FEATURES A 7 KG PAYLOAD CAPACITY, A 911 MM HORIZONTAL REACH, AND A REPEATABILITY OF ±0.03 MM. WITH A MECHANICAL MASS OF 27 KG, IT IS THE LIGHTEST UNIT IN ITS CLASS, FACILITATING FLEXIBLE MOUNTING OPTIONS INCLUDING FLOOR, INVERTED, AND ANGLE ORIENTATIONS. THE ROBOT IS ENGINEERED FOR HIGH-PERFORMANCE MOTION, WITH AXIS SPEEDS REACHING UP TO 370°/S FOR J1, 310°/S FOR J2, 410°/S FOR J3, 550°/S FOR J4, 545°/S FOR J5, AND 1000°/S FOR J6. ITS MOTION RANGES ARE J1 ±360°, J2 ±245°, J3 ±420°, J4 ±380°, J5 ±250°, AND J6 ±720°. THE SLIM ARM DESIGN INCLUDES INTEGRATED INTERNAL CABLING AND PIPING TO MINIMIZE INTERFERENCE IN COMPACT WORKSPACES. THIS UNIT IS EQUIPPED WITH A FANUC R-30IB MATE PLUS COMPACT CONTROLLER, CONNECTION CABLES, AND A MECHANICAL ARM. IT IS SUITABLE FOR A WIDE RANGE OF INDUSTRIAL APPLICATIONS SUCH AS ASSEMBLY, MACHINE TENDING, PICKING, PACKAGING, AND MATERIAL HANDLING, OFFERING IP67 PROTECTION FOR THE WRIST AND BODY TO ENSURE DURABILITY IN VARIOUS ENVIRONMENTS.
