Kentucky
Aucto ID: #95621
Buy Now
Verified Seller

2016 Mazak Nexus Vcn 700E/40-II 4-Axis CNC Machining Center, 12K RPM, Upgraded Features

Asking Price:
$169,500.00

Financing From: $2,809/mo

Get pre-approved in minutes — no credit impact

Apply

Delivery Options

Rigging · Included

Loading · Included

Shipping · Buyer or

Removal Deadline · 30 days

Product Description

New 2016 only 5040 Cutting Hours X - 80" Y - 27.6" Z - 28.3" Power - 25 hp RPM - 12,000 RPM # ATC - 30 Taper - 40 Pallet-W - 27.5" Pallet-L - 80" # Axis - 4 Control - CNC (Matrix Nexus II control) Dimensions - 198" x 139" x 140" Weight - 26,500 LBS Mazak VCN 700E/40-II 4 Axis VMC New 2016 Nikken 302MA CNC Rotary Table Low Hours only 5040 Cutting Hours High Pressure thru Tool Coolant System Chip Conveyor Certified Inspection Report from Mazak Tech. General Specifications: X Axis Travel: 80" Y Axis Travel: 27.6" Z Axis Travel: 28.3" Spindle Motor: 25 HP Spindle Speed: 12,000 RPM Spindle Taper: 40 Tool Changer: 30 ATC Table Size: 80" x 27.5" Dimensions: 187" x 140" x 140" Weight: 26,500 LBS Specs: Matrix Nexus 2 Control 12.1” Color LCD EIA/ISO Code Input Function Additional EIA/ISO Functions LAN Port in Electrical Cabinet USB I/F (2 Port) Absolute Encoder System Manual Pulse Generator 1 Dial (Detachable) 80” x 27.5” Table with T-Slots 30 Tool Magazine (CAT-40) Total Cover without top cover Hi-Press. Coolant Thru Spindle System Roller Guide X-axis travel 80” Y-axis travel 27.55” Operator door with interlock with lock-switch Cover coolant Dry Pit Foundation with complete toe-clamp Main spindle motor 25 HP Spindle Speed 12,000 RPM Power Transformer Relocation Device Windows 7 Operating System Hand Held Coolant Nozzle BJGOO Slope Constant BJMAZACC -2D Software (Shape Compensation) Nikken CNC 302MA NC Rotary Table Package Mazak VCN 700E/40-II 4 Axis VMC New 2016 Nikken 302MA CNC Rotary Table Low Hours only 5040 Cutting Hours High Pressure thru Tool Coolant System Chip Conveyor Certified Inspection Report from Mazak Tech. General Specifications: X Axis Travel: 80" Y Axis Travel: 27.6" Z Axis Travel: 28.3" Spindle Motor: 25 HP Spindle Speed: 12,000 RPM Spindle Taper: 40 Tool Changer: 30 ATC Table Size: 80" x 27.5" Dimensions: 187" x 140" x 140" Weight: 26,500 LBS Specs: Matrix Nexus 2 Control 12.1” Color LCD EIA/ISO Code Input Function Additional EIA/ISO Functions LAN Port in Electrical Cabinet USB I/F (2 Port) Absolute Encoder System Manual Pulse Generator 1 Dial (Detachable) 80” x 27.5” Table with T-Slots 30 Tool Magazine (CAT-40) Total Cover without top cover Hi-Press. Coolant Thru Spindle System Roller Guide X-axis travel 80” Y-axis travel 27.55” Operator door with interlock with lock-switch Cover coolant Dry Pit Foundation with complete toe-clamp Main spindle motor 25 HP Spindle Speed 12,000 RPM Power Transformer Relocation Device Windows 7 Operating System Hand Held Coolant Nozzle BJGOO Slope Constant BJMAZACC -2D Software (Shape Compensation) Nikken CNC 302MA NC Rotary Table Package Mazak VCN 700E/40-II 4 Axis VMC New 2016 Nikken 302MA CNC Rotary Table Low Hours only 5040 Cutting Hours High Pressure thru Tool Coolant System Chip Conveyor Certified Inspection Report from Mazak Tech. General Specifications: X Axis Travel: 80" Y Axis Travel: 27.6" Z Axis Travel: 28.3" Spindle Motor: 25 HP Spindle Speed: 12,000 RPM Spindle Taper: 40 Tool Changer: 30 ATC Table Size: 80" x 27.5" Dimensions: 187" x 140" x 140" Weight: 26,500 LBS Specs: Matrix Nexus 2 Control 12.1” Color LCD EIA/ISO Code Input Function Additional EIA/ISO Functions LAN Port in Electrical Cabinet USB I/F (2 Port) Absolute Encoder System Manual Pulse Generator 1 Dial (Detachable) 80” x 27.5” Table with T-Slots 30 Tool Magazine (CAT-40) Total Cover without top cover Hi-Press. Coolant Thru Spindle System Roller Guide X-axis travel 80” Y-axis travel 27.55” Operator door with interlock with lock-switch Cover coolant Dry Pit Foundation with complete toe-clamp Main spindle motor 25 HP Spindle Speed 12,000 RPM Power Transformer Relocation Device Windows 7 Operating System Hand Held Coolant Nozzle BJGOO Slope Constant BJMAZACC -2D Software (Shape Compensation) Nikken CNC 302MA NC Rotary Table Package https://www.youtube.com/watch?v=HJp_tFqm25w

Core Specifications

Manufacturer: MAZAK

Model: NEXUS VCN 700E/40-II

Year: 2016

Serial Number / VIN: 268867

Packaging Type: 1 Piece

Condition: Good - Item functions as originally intended, shows minimal signs of wear.

Usage: 5,040 hours
